100m 120m 150m water tank wheel tracto WATER WELL DRILLING RIG water well drilling truck borehole drilling machine

SRJKC300 300m TRUCK MOUNTED WATER WELL DRILLING RI water well drill rig shallow water well drilling equipment

DESCRIPTION

JKCS300 truck mounted versatile well drilling rig is a new, efficient and multifunctional hydraulic rig, mainly applicable to all kinds of drilling process of wells, monitor boreholes, geothermal boreholes, and grouting holes of cofferdam, dam and reinforced base, as well as drilling of open pit mining, anchor reinforcement project and defense project. The rig equips with powerful hydraulic motor, heavy hydraulic drilling arm and high pressure DTH percussive hammer, and its drilling speed is faster than other type of rigs.

SPECIFICATIONS

SPECIFICATIONS OF SRJKCS300 VERSATILE WELL DRILLING RIG

Borehole Diameter	φ105-350mm
Borehole Drilling Depth	300m
Working Air Pressure	1.05-3.05MPa
Air Consumption	16-35m?/min
Rod Diameter	φ89mm, φ102mm, φ114mm
Rod Length	3m / 4.5m
Grade Ability	15°

WINCH SYSTEM ( STANDARD MAIN WINCH & OPTIONAL TOOLING WINCH)

Lifting Force	15t
Lifting Height	8m

FEED SYSTEM

Axial Pressure	±6t
Rotation Torque	4500N.m
Rotation Torque	8500N.m
Rotation Rate	0-80rpm
Rotation Rate	0-160rpm
Weight	8t (excluding vehicle)
Dimension (L x W x H)	10500mm x 2480mm x 3050mm (transport)
Working Size (L x W x H)	11000mm x 2480mm x 7147mm

100m 120m 150m water tank wheel tracto WATER WELL DRILLING RIG water well drilling truck borehole drilling machine

==============================================

please feel free contact us, whatsapp/wechat::008615021099979

====================================================

FY600/F800 CRAWLER WATER WELL DRILLING RIG

FY600/F800 Crawler Water Well Drilling Rig

DESCRIPTION

600M 800M depth Water Well Drilling Rig
100m 120m 150m water tank wheel tracto WATER WELL DRILLING RIG water well drilling truck borehole drilling machine
Product Features

● This model rig uses full hydraulic control, and the Top drive to drive the rotation of drilling tools with very high drilling efficiency.

● Reasonable overall layout uses the tractor-mounted or full ground chassis for transportation with good maneuverability.

● Very flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, the shallow
layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.
● The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as slurry drilling, air
drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.

SPECIFICATION

FY600 CRAWLER WATER WELL DRILLING RIG

Drilling Depth	600m
Drilling Diameter	140-350mm
One-Time Advance Length	6.60m
Walking Speed	2.50km/h
Climbing Angles	30 degree
Engine Power	118KW
Work Air Pressure	1.7-3.5 Mpa
Air Consumption	17-42m3/min
Drill Pipe Length	2m, 3m, 6m
Drill Pipe Diameter	102mm, 108mm, 114mm
Rig Lifting Force	28 ton
Rotary Speed	45-115 rpm
Rotary Torque	8500-11000 N.m
Weight	12000KG
Dimensions	600022002850mm

FY800 CRAWLER WATER WELL DRILLING RIG

Drilling Depth	700m
Drilling Diameter	140-400mm
One-Time Advance Length	6.60m
Walking Speed	2.50km/h
Climbing Angles	30 degree
Engine Power	140KW
Work Air Pressure	1.7-3.5 Mpa
Air Consumption	17-42m3/min
Drill Pipe Length	2m, 3m, 6m
Drill Pipe Diameter	102mm, 108mm, 114mm
Rig Lifting Force	30 ton
Rotary Speed	55-120 rpm
Rotary Torque	8850-13150 N.m
Weight	13000KG
Dimensions	610022002900mm

==================================================================================
please feel free contact us, whatsapp/wechat::008615021099979

=====================================================

FY600 CRAWLER WATER WELL DRILLING RIG

Drilling Depth	600m
Drilling Diameter	140-350mm
One-Time Advance Length	6.60m
Walking Speed	2.50km/h
Climbing Angles	30 degree
Engine Power	118KW
Work Air Pressure	1.7-3.5 Mpa
Air Consumption	17-42m3/min
Drill Pipe Length	2m, 3m, 6m
Drill Pipe Diameter	102mm, 108mm, 114mm
Rig Lifting Force	28 ton
Rotary Speed	45-115 rpm
Rotary Torque	8500-11000 N.m
Weight	12000KG
Dimensions	600022002850mm

FY800 CRAWLER WATER WELL DRILLING RIG

Drilling Depth	700m
Drilling Diameter	140-400mm
One-Time Advance Length	6.60m
Walking Speed	2.50km/h
Climbing Angles	30 degree
Engine Power	140KW
Work Air Pressure	1.7-3.5 Mpa
Air Consumption	17-42m3/min
Drill Pipe Length	2m, 3m, 6m
Drill Pipe Diameter	102mm, 108mm, 114mm
Rig Lifting Force	30 ton
Rotary Speed	55-120 rpm
Rotary Torque	8850-13150 N.m
Weight	13000KG
Dimensions	610022002900mm
